BioLife Solutions Model 2101 Controlled Rate Freezing System | 1 cu. ft. (28 Liters)

Item#: 2101

The 2101 Controlled Rate Freezer provides the ultimate freezer temperature control system for temperatures down to -180°C. Utilizing a password protected laptop controller with Windows based operating system; this unit offers unlimited programming capability and temperature set points either by samples or the chamber.

Standard System Consists of:
  • Laptop controller with 2100 software
  • Freezing chamber
  • Choice of sample rack
  • 4ft transfer line
REQUEST PROPOSAL
Supplier:

Power requirements:

  • 120 volt 50/60 Hz, 10 amp
  • 230 volt 50/60 Hz, 10 amp



Outside dimensions:

  • Depth: 25 1/2"(648mm) (including vent)
  • Height: 29 1/4"(743mm) (including computer)
  • Width: 19 1/16"(484mm) (Including Hose Connection)

Inside Dimensions:

  • Depth: 9 9/16"(243mm)
  • Height: 13 3/4"(349mm)
  • Width: 14"(356mm)
  • 28 liters
  • Laptop controller using Windows based operating system.
  • Unlimited programming capability.
  • Multi-color graphing of sample, chamber and program temperature.
  • Temperature set points by sample or chamber.
  • Programs and freeze data saved to hard drive or disc.
  • Password protected software.
  • Searchable database for freeze run history.
  • Freeze run graphs and data available via any standard USB printer.
  • 30 data fields available for each freeze run.
  • Continuous digital and graph display for time and temperature during operation.
  • Manual overrides for all operating functions.
  • Temperature range +50°C to -180°C.
  • Freezing rates of 0.01° to 99.9° per minute.
  • Program temperature hold of 1 second to 99 hours.
  • Six pre-set easy to run freeze programs.

BioLife Solutions Model 2101 Controlled Rate Freezer Information Sheet

Download

Custom BioGenic Systems 2101 Controlled Rate Freezer Set-Up & User Manual

Download
