IC Biomedical AI24-11 Artificial Insemination Cryogenic Refrigerator with (6) 11″ Canisters (960 x 1/2 cc Straws)

Item#: AI24-11M

The AI24 animal insemination cryogenic refrigerator from IC Biomedical provides greater capacity and security for storage at cryogenic temperatures, with the durability and performance needed under the most rugged conditions.

$1,470.00 $1,249.50

Add to wishlist
REQUEST PROPOSAL
Supplier:
  • Static Holding Time Days; 218
  • Working Time Days: 137
  • Evaporation Rate liters/days: 0.11
  • Liquid Nitrogen Capacity liters: 24
  • Weight Empty lbs.(kg.): 26.2 (11.9)
  • Weight Full  lbs.(kg.): 69.0 (31.3)
  • Neck Diameter  in.(mm.): 2.38 (60.4)
  • Overall Height in.(mm.): 25.8 (655)
  • Overall Diameter  in.(mm.): 15.6 (396)
  • Number of Canisters: 6
  • Canister Dimensions in. (mm.): 1.89x11 (48x279)
  • Number of 1.2 ml & 2.0 ml vials (5/cane): 288
  • Number of 1/2 cc straws (10/cane): 960
  • Number of 1/4 cc straws (28/cane): 2688
*Comes complete with a Necktube Core.
**Straws, canes and vials are not included.

(1) Evaporation rate and static holding time are nominal. Actual rate may be affected by the nature of the contents, atmospheric conditions, container history, and manufacturing tolerances.
(2) Work time is an arbitrary, reference-only value to estimate container performance under the actual operating conditions.

  • Rugged:  Lightweight ribbed aluminum exterior construction and magneformed joints for maximum structural  integrity.
  • Reliable: Designed and constructed to stringent specifications and the highest quality requirements.
  • Ready: When you need it, samples can be easily retrieved and stored for an extended period of time.
  • 5 year vacuum warranty

ICBiomedical AI24 Spec Sheet

Download
