- Cu. Ft.: 25.2
- Door(s): (1) solid swing door (glass viewing window available upon request)
- Temperature Range: +35°C to +70°C (+/- 0.3°C Volumetric Uniformity)
- Exterior Dimensions: 41” W x 34.5” D x 76.5” H
- Interior Dimensions: 34” W x 28.5” D x 45” H
- 304 SS interior (SS exterior and 316 SS available upon request)
- Alarms: Audible and visual; numerous programmable
- Casters: Yes, plus leveling bolts
- Shelves: (4) included; (14) max; adjustable
- Door Lock: Front
- Access port: 1-inch port standard; 2-inch and 3-inch available upon request
- Electrical Requirements: 208/230V, single phase, 30A (120V or 220-240V 50Hz with CE mark available upon request)
- Shipping Weight: 425 lbs.
- Touchscreen LCD controller
- High and low voltage wiring separated for safe servicing (NFPA 70E Compliant)
- 2-way (RS-485) or 1-way (4-20mA) communication to controller
- Horizontal air flow across full vertical height of chamber for uniform distribution
- Integrated refrigeration equipment on top of chamber
- 3A duplex receptacle available upon request
- Chart recorder available upon request
- Class I Div 2 construction available upon request
- Electrofin coil coating for corrosive environments available upon request
- Internal lighting available upon request
- UPS available upon request
- 20-year design life
- MET listed
- Warranty: 12 months parts and labor
Request a Proposal
