Performance Data Temperature
- Temperature range (max. 24 °C under ambient temp): 0°C -70°C
- Temperature variation at 40 °C [± K]: 0.3°C
- Temperature fluctuation at 40 °C [± K]: 0.1°C
- heat compensation at 40 °C [W]: 250°C
Performance Data Climate
- Temperature range (max. 24 °C under ambient temp) 5°C -70°C
- Temperature variation at 25 °C and 60 % RH [± K]: 0.1°
- Temperature variation at 40 °C and 75 % RH [± K]: 0.2
- Temperature fluctuation at 25 °C and 60 % RH [± K]: 0.1
- Temperature fluctuation at 40 °C and 75 % RH [± K]: 0.1
- Humidity range [% RH] 10%-80%
- Humidity fluctuation at 25 °C and 60 % RH: 0,3 % RH
- Humidity fluctuation at 40 °C and 75 % RH: 0,3 % RH
- Recovery time after 30 seconds door open at 25 °C and 60 % RH [min] 5
- Recovery time after 30 seconds door open at 40 °C and 75 % RH [min] 11
Electrical data
- Rated Voltage [V] 100-120
- Power frequency [Hz] 50/60
- Nominal power [kW] 0.8
- Unit fuse [A] 16
- Phase (Nominal voltage) 1~
Measures
- Interior volume [cu.ft.] 8.7
- Net weight of the unit (empty) [lbs] 322
- Permitted load [lbs] 220
- Load per rack [lbs] 66
- Wall clearance back [in] 3.94
- Wall clearance sidewise [in] 3.94
Internal Dimensions
- Width [in] 25.61
- Height [in] 30.93
- Depth [in] 19.11
Doors
- Unit doors: 1
Housing dimensions not incl. fittings and connections
- Width net [in] 36.64
- Height net [in] 57.5
- Depth net [in] 31.52
Environment-specific data
- Energy consumption at 40 °C and 75 % RH [Wh/h] 85
- Sound-pressure level [dB(A)] 46
Fixtures
- Number of shelves (std./max.) 2/9
