Biomek i7 Liquid Handling Automated Workstation

Item#: BIOMEK-I7

The Biomek i7 Automated Worktstation from Beckman Coulter is an industry leading liquid handler. Optimizing dependability and walk-away time, these workstations are ideal for medium to high throughput workflows.

REQUEST PROPOSAL
Supplier:
  • Part Number Product Name Weight Power Requirements Temperature Range

    C02613

    		 Mobile Workstation, i7 225 kg / 496 lb N/A

    B87588

    		 Biomek i7 Span-8 with enclosure 225 kg / 496 lb 100-240 VAC, 50/60 Hz, 10 A

    10° C - 30°C

    B87587

    		 Biomek i7 Multichannel with enclosure 234 kg / 515.9 lb 100-240 VAC, 50/60 Hz, 10 A 10° C - 30°C

    B87586

    		 Biomek i7 Dual-Multichannel with enclosure 269 kg / 593 lb 100-240 VAC, 50/60 Hz, 10 A

    10° C - 30°C

    B87585

    		 Biomek i7 Hybrid (MC + Span-8) with Enclosure 260 kg / 573.2 lb 100-240 VAC, 50/60 Hz, 10 A

    10° C - 30°C
    B87582 Biomek i7 Span-8 without enclosure 190 kg / 418.9 lb 100-240 VAC, 50/60 Hz, 10 A

    10° C - 30°C
    B87579 Biomek® i7 Hybrid (MC + Span-8) without Enclosure 225 kg / 496 lb 100-240 VAC, 50/60 Hz, 10 A

    10° C - 30°C

Versatile Workspace

  • Spacious, open-platform with grid-based deck
  • Up to 45 deck positions
  • Internal LED light
  • Automated Labware Positioners (ALPs) for sample processing
  • Optional enclosed version to protect samples from airborne particles
  • Integrate additional devices on- or off-deck
  • Configurable for specific applications

Flexible Pipetting and Workflow Management

  • Multiple single- & dual-arm configurations with Multichannel heads (96/384/Pin tool) and/or Span-8 pipetting
  • Large-volume 1 mL multichannel pipetting head
  • High-access, rotating gripper(s) with unique offset finger design
  • Disposable & fixed Biomek pipette tips (including septum piercing)
  • Transfer volumes from 0.5 µL - 5,000 µL
  • Independent Span-8 probe calibration
  • 8 channel liquid-level sensing
  • Supports labware from tubes to 1,536-well microplates
  • Accurate intra-well pipetting

Simple System Operation

  • Easily automate existing processes & execute quick workflow changes
  • Powered by icon-based software with data tracking & LIMS connectivity
  • Windows 10 OS
  • Extend walk-away operation with process management & scheduling software
  • Guided system setup
  • Automated deck framing
  • Data-driven method operations including hit-picking & normalization
  • Light curtain safety feature
  • Instrument status light bar
  • DeckOptix cameras for live, remote-monitoring & on-error video capture

Application-focused Solutions

  • Consultative workflow analysis
  • Expert application & technical support
  • Biomek-automated demonstrated methods & capabilities for genomic, drug discovery & basic research workflows
