Caron Model RC Laboratory Automation & Robotic Enclosure Systems

Item#: RC180P

The RC Class II Enclosures are equipped with pre-filtration which eliminates particles of 5.0μm or larger to an efficiency of 92% as per BS EN ISO 779 standards.

REQUEST PROPOSAL
Supplier:

Model

 External Dimensions mm (WxDxH) Internal Dimensions mm (WxDxH)

RC180P

 1800 x 1400 x 2570

1720 x 1200 x 1063

RC220Q

 2200 x 1400 x 2570

2120 x 1200 x 1063

RC260R

 2600 x 1400 x 2570

2520 x 1200 x 1063
RC300S 3200 x 1400 x 2570

2920 x 1200 x 1063



  • Sound level: <65dBA
  • Lighting: 2 x 18W sealed fluorescent amps >480lux
  • 110V, AC, 60Hz, 20Amp, 1Ø
  • Offers in-process operator and product protection with access through 325mm high sliding windows.
  • Comes with a programmable control system that displays the status of the enclosure and controls the airflow balance, with an hour counter.
  • Exterior mounted display shows the status of the enclosure
  • Great visibility of the enclosed system.
  • Audible and visual alarm signals low airflow and door open warning.
  • Display/lighting showing status of enclosed robotic system (with option for status lighting above control display position)

Additional Features

  • Computer shelf on a flexible arm
  • Additional electrical sockets to fit the robotic system
  • Integrated robot system safety switches
  • Under-bench storage, shelving, and cupboards to fit
  • Universal control panel with linked UV lighting and timed on/off control
  • Ventilated waste tips and plate containers

Caron RC Enclosure for Operator Protection- Literature

Download

Caron Family of Products Brochure

Download
