- External Dimensions (W × D × H): 31.1" × 34.7" × 78.5" | 790 × 882 × 1993mm
- Internal Dimensions (W × D × H): 24.8" × 23.6" × 55.1" | 630 × 600 × 1400mm
- Volume: 18.6 cu. ft. (528 liters)
- Net Weight: 531 lbs (241 kg)
- Capacity (2" boxes): qty 384
- Capacity (3" boxes): qty 256
- Inventory Racks (2" boxes): qty 16
- Inventory Racks (3" boxes): qty 16
- Temperature Control Range: -40°C to -86°C
- Uniformity: +/-3°C (-80°C Set point)
- Power Consumption (kWh/Day): 4.99 (-80 °C Steady State)
- BTU Nominal: 710 Per Hour
- Noise Level: 52 dB(A)
- Ambient Temperature Operating Range: +5 to +30°C
- Power Supply:
- 115V, NEMA 5-15P, 60 Hz 8ft cord length (standard configuration)
- Dual Voltage Option:
- 220V, NEMA 6-15P, 60 Hz 8ft cord length (220V power cord in chamber with standard accessories)
- 115V, NEMA 5-15P, 60 Hz 8ft cord length (standard configuration)
- Max Amps: 8.5
- Certification: QPS Listed and Energy Star
- Warranty: 5 years parts and labor
Control:
- Controller: Microprocessor with non-volatile memory, USB connectivity, IOT Ready
- Digital Temperature Display: LCD Touchscreen
- Controller Security: Screen lock w/ password protection, facial recognition, NFC
- Temperature Sensor: RTD
Refrigeration:
- Cooling Method: Cold Wall (Synchronized variable speed cascade system)
- Compressors (High Stage I Low Stage): 750 W Variable | 750 W Variable
- Refrigerant Type (Natural Refrigerant): High Stage I Low Stage R-290 | R-170
- Insulation: Rigid polyurethane foam (PUF) + VIP Plus vacuum insulated panels
Construction:
- Exterior Material: Painted steel
- Interior Material: Painted steel
- Outer Door: qty 1 lock with set of 2 keys and electronic lock (provision for optional pad lock)
- Inner Doors: qty 2 insulated stainless steel with latch
- Shelves: qty 3 (adjustable)
- Shelf Dimensions (W × D): 24.2" × 21" (615 × 534mm)
- Max. Load per Shelf: 110 lbs (50 kg)
- Access Ports, Qty, Position, Diameter: qty 3: upper wall (back-up system), bottom left (recorder sensor), bottom right (access) 0.6 in | 17mm
- Casters | Leveling Legs: qty 4 | 2
- Vacuum Release: qty 1 Auto
