- Static Holding Days(1): 74
- Working Time Days(2): N/A
- Evaporation Rate(1): 8
- Liquid Nitrogen Capacity: 590 liters
- Weight Empty: 565 lbs. / 256 kg
- Weight Full: 1,616 lbs. / 733 kg
- Neck Diameter: 39” / 991mm
- Overall Height: 49” / 1,245 kg
- Overall Dimensions(4): 42” / 1,067mm
- Usable Height (internal): 29” / 737mm
- Internal Diameter(5): 39” / 991mm
Capacity:
- 2ml Plastic Vials(6): 38,350
- No. of 100/81 Cell Racks: 28
- No. of 25 Cell Racks: 6
- No. of Shelves: 13
- Standard Box Size:
- Shape: square
- Size(8): 5" x 5" / 127 x 127mm
- Vials per box: 100
- Mini Box Size:
- Shape: square
- Size(8): 3" x 3" 76 x 76mm
- Vials per box: 25
- # of 0.50cc straws (two tier turn-table): 114,000
*Unit does not come with transfer hose and connector(fitting). If required, both must be ordered separately.
(1) Evaporation rate and static holding time are nominal. Actual rate may be affected by the nature of the contents, atmospheric conditions, container history, and manufacturing tolerances.
(2) Working Time is an arbitrary, reference-only value to estimate container performance under the actual operating conditions.
(4) Maximum depth 55.0 in (1397mm). Maximum height 90.0 in. (2286 mm) with lid open.
(5) Temperature Gradient Suppression System reduces internal diameter by approx. 1/4 in. (6.4 mm).
(6) 2.0 ml vial size: 12.5 mm O.D. internal thread
(8) The 38K container utilizes both the 5 in. x 5 in. (127 mm x 127 mm) 100/81 cell box and the 3 in. x 3 in. (76 mm x 76 mm) 25 cell box.
